XCU-6A Underground Maintenance Vehicle
Product Information Quick View
· Equipment condition
brand new
· Customizable Situation
yes
· Price range
negotiable
· Primary application field
Underground Maintenance
description
XCU-6A Underground Maintenance Vehicle
Các XCU-6A Underground Maintenance Vehicle is a specialized service vehicle developed by our company for non-coal underground mining operations, particularly in tunnel construction and equipment maintenance scenarios. Designed based on the unique operational conditions of underground metal and non-metal mines, the XCU-6A integrates advanced domestic and international technologies to ensure high adaptability, reliability, and safety.
This model is purpose-built for equipment maintenance tasks in underground metal mines, offering multiple integrated functions:
-
Temporary power supply connection
-
Onboard air compressor
-
Vehicle-mounted crane for lifting operations
-
Portable electric welding capabilities
Key Features:
-
Dual Chassis Options: Available with 6-ton or 10-ton chassis to accommodate varying load and operational needs.
-
Articulated Frame Design: The vehicle uses a center-articulated structure, enabling tight turning radius and high maneuverability in narrow tunnels and confined underground environments.
-
Low-profile and Narrow Body: Specially engineered to operate in tunnels with limited height and width.
-
Customizable Modules: Optional features and tools can be added according to customer-specific operational requirements, allowing for tailored configurations to meet diverse project needs.
The XCU-6A ensures that underground maintenance operations such as electrical hookups, compressed air supply, lifting, and welding can be performed efficiently and safely with minimal equipment footprint. Its multi-function integration, compact design, and high mobility make it an essential support vehicle in modern underground mining and tunneling operations.
image gallery
Specifications
Vehicle Parameters
| Item | Sub-item | XCU-6A |
|---|---|---|
| Load Capacity (KG) | — | 6000 |
| Curb Weight (KG) | — | 10000 |
| Max. Climbing Angle (°) | — | 15 |
| Max. Speed (km/h) | — | 25 |
| Dimensions: Length (mm) | — | 7930 |
| Dimensions: Width (mm) | — | 1950 |
| Dimensions: Height (mm) | — | 2570 |
| Wheelbase (mm) | — | 3650 |
| Track Width (mm) | — | 1560 |
| Min. Ground Clearance (mm) | — | ≥270 |
| Front Axle Oscillation Angle (°) | — | ±8 |
| Engine Model | — | F4.5C54119 |
| Engine Total Power | — | 88kW |
| Transmission Model | — | HTCE3322ILD |
| Front Axle | — | Fenyi Drive Axle DR3022A-1(Q) |
| Rear Axle | — | Fenyi Drive Axle DR3022A-1(H) |
| Steering System Type | — | Full Hydraulic Steering |
| Steering Angle (°) | — | 40 |
| Min. Turning Radius (m) | Inner | 4030±200 |
| Outer | 6350±200 | |
| Forward Speed (km/h) | Gear I | 5.5 |
| Gear II | 12 | |
| Gear III | 25 | |
| Reverse Speed (km/h) | Gear I | 5.5 |
| Gear II | 12 | |
| Gear III | 25 |
Additional Equipment
| Item | XCU-6A |
|---|---|
| Generator Model | WPG33/B13 |
| Generator Rated Power (KW) | 24 |
| Generator Output Voltage (V) | Three-phase 400/230 |
| Oil-free Air Compressor Model | UPS-5TAS-14-272 |
| Air Compressor Rated Power (KW) | 5.5 |
| Air Compressor Output Pressure (bar) | 14 |
| Air Compressor Air Delivery (m³/min) | 0.51 |
| Crane Model | FS404J |
| Lifting Capacity Requirement | 800kg at 4.5m radius |
| Max. Lifting Moment (KN.m) | 40 |
| Crane Max. Working Radius (m) | 4.5 |
| Crane Rotation Angle (°) | ±165 |
| Welding Machine Model | ZX7-315B1 |
| Welding Machine Input Power (V/Hz) | 380 50/60 |
| Welding Machine Rated Input Capacity (KVA) | 11.5 |
Application industries & materials
Các XCU-6A Underground Maintenance Vehicle is primarily used in underground tunnels of metal and non-metallic mines, offering mobile, multi-functional maintenance support for a wide range of equipment during both construction and operational phases.
It is especially valuable in underground environments with limited space, complex access routes, and high demands for repair efficiency. Thanks to its compact structure, integrated utility systems, and high maneuverability, the XCU-6A plays a key role in enhancing mine operational resilience and service continuity.
Typical application scenarios include:
-
Emergency repair and routine inspection of mining equipment in underground stopes
-
Temporary maintenance of drainage and conveyor systems in non-coal mines
-
Power and compressed air supply during equipment setup in mine infrastructure projects
-
Support for welding and lifting operations in tunnel construction
-
Rapid deployment platform for emergency underground repair teams
